Specifications

Image Sensing Device
Sensor 1/2.3 type
Number of effective pixels Approx. 8.29 million pixels
Lens
Magnification 20x
Focal length 30.6mm – 612mm
Aperture Iris diaphragm (8-blade)
Image stabilizer Optical system (w/Powered IS/Dynamic mode)
Lens control 1 Ring (Zoom / Focus)
ND filter Yes
Image processing platform DIGIC DV6
Infrared camera support Yes
LCD Panel 3.0 inch (7.5cm), approx. 460,000 dots
Capacitive touch panel
Color viewfinder (CVF) 0.24 inch tilting
Approx. 1,560,000 dots
Codec MP4
Recording format
MP4 3840 x 2160 (150 Mbps)
YCC420 8 bit
PAL: 25P
NTSC: 29.97P/23.98P

1920 x 1080 (35/17 Mbps)
YCC420 8 bit
PAL: 50.00P/25.00P
NTSC: 59.94P/29.97P/23.98P

1280 x 720 (8 Mbps)
YCC420 8 bit
NTSC: 59.94P
Audio MPEG-2 AAC-LC (16-bit 2CH) /
LPCM (16-bit) 4CH
S&F recording 0.5x slow (50 FPS @ 1920 x 1080)
Color sample/Bit depth 4:2:0 8 bit (MP4)
Slow & Fast 50/59.94 FPS @ 1920 x 1080 (25.00P/29.97P)
Lock Setting Standard
Recording media SD Cards (2 slots), UHS-I standard supported
Terminals
SDI-OUT Full HD (50p/50i/59.94p/59.94i 4:2:2 8 bit)
HDMI Full HD (50p/50i/59.94p/59.94i 4:2:2 8 bit)
Shoe Cold Shoe
Ethernet terminal No
Others Headphone terminal, mic jack, USB (mini-B), Remote A 2.5mm, HDMI out
Handle unit XLR input, IR Light, Zoom Lever, REC Button,
tally lamp, cold shoe
Battery pack Battery Pack BP-820/BP-828
Dimensions (W) x (H) x (L) 131 x 180 x 231mm
Weight 1120g
Compact power adapter CA-570
