Specifications

Image Sensing Device
Sensor 1.0 inch (3.2μm)
Number of effective pixels Approx. 8.29 million pixels
Lens
Magnification 15x
Focal length 25.5mm-382.5mm
Aperture Iris diaphragm (9-blade)
Image stabilizer Optical system (w/Powered IS/Dynamic mode)
Lens Control 3 Ring (Zoom, Focus, Iris)
ND filter 3 densities: Switched with turret
Focus Dual Pixel CMOS AF, MF (Dual Pixel Focus Guide support)
Image processing platform Dual DIGIC DV6
HDR Support Hybrid Log Gamma (HLG) and Perceptual Quantization (PQ)
Infrared camera support Yes
LCD Panel 4.0 inch (10.1 cm), wide-screen color LCD,
approx. 1,230,000 dots
Capacitive touch panel
Color viewfinder (CVF) 0.46 inch (1.18 cm on the diagonal),
approx. 1,770,000 dots
Color wide-screen organic EL display
Codec H.265/HEVC, H.264/AVC
Recording format
XF-HEVC 3840 x 2160 (160/110 Mbps)/
1920 x 1080 (60/45 Mbps)
YCC422 10 bit
NTSC: 59.94P / 59.94i / 29.97P / 23.98P
PAL: 50.00P / 50.00i / 25.00P

1920 x 1080 (45 Mbps)
YCC420 8 bit
NTSC: 59.94P / 29.97P / 23.98P
XF-AVC PAL: 50.00P / 25.00P
Audio Linear PCM: 24 bit / 48 kHz / 4 channels
S&F recording 0.2x slow (100fps/120fps @ 1920 x 1080)
Color sample/Bit depth 4:2:2 10 bit (XF-HEVC), 4:2:0 8 bit (XF-AVC)
Slow & Fast 100/120fps @ 1920 x 1080 (25.00P/29.97P)
Gamma Support Normal 1-4 / Wide DR, Canon Log 3. PQ, HLG
Recording media SD Cards (2 slots), UHS-I U3 standard supported
Terminals
SDI-OUT 12G/6G/3G/HD-SDI (4K UHD/50.00P, 4:2:2 10 bit)
HDMI 4K UHD (50.00P/59.94P, 4:2:2 10 bit)
Shoe Cold Shoe
Ethernet terminal Yes
Others Headphone, mic, USB (mini-B), Remote A,
Remote B(RS422), LAN, GENLOCK/SYNC OUT,
TIME CODE
Handle unit Zoom, Record, Menu, Playback functions
Battery pack Battery Pack BP-A30/BP-A60
Dimensions (W) x (H) x (L) 191 x 210 x 383mm
Weight 3160g
Compact power adapter CA-CP200L
Wi-Fi YES (5 GHz also supported)
Network Specifications
Standards IEEE 802.11b/g/n (2.4 GHz band),
IEEE 802.11a/n (5 GHz band)
Wi-Fi logo certification acquired
Transmission Frequencies and channels ■ IEEE 802.11b/g/n (2.4 GHz band),
2412-2462 MHz, 1-11 ch (NTSC models only)
2412-2472 MHz, 1-13 ch (PAL models only)
■ IEEE 802.11n/11a (5 GHz band): Differs depending on the model’s destination.
Connection method
  1. Infrastructure mode [Wi-Fi connection]
  2. Camera access point [mode in which the XF705 operates to process similar to an access point (AP)]
  3. Ethernet [LAN cable connection]
Wi-Fi setting method
  1. WPS [Wi-Fi Protected Setup] (push-button system, PIN code system)
  2. Manual setup
  3. Search for access points
Encryption systems*1 WEP / TKIP / AES

Supplementary note: When manually configuring
Wi-Fi for the XF705, select
“OPEN / NONE / WEP”, “Share key / WEP”, “WPA-PSK / TKIP-AES”, or “WPA2-PSK / TKIP / AES"
IP address settings Auto [automatic switching between DHCP and AutoIP]/manual [IP address, subnet mask, default gateway, priority DNS server (primary server), substitute DNS server (secondary server) settings]
Network Connection Services
Camera mode Remotely controls the XF705 from a web browser on a tablet or smartphone
Browser remote Verified operating systems and devices: (to be provided later)
Media mode
FTP file transfer
This function is used to transfer data to the FTP server.
The frequency bands and maximum transmission speeds of the Wi-Fi standards supported by XF705 are listed in the table below.
Standards Frequency band Maximum transmission speed
IEEE 802.11a 5 GHz Max. 54 Mbps
IEEE 802.11b 2.4 GHz Max. 11 Mbps
IEEE 802.11g 2.4 GHz Max. 54 Mbps
IEEE 802.11n 2.4 GHz/5 GHz Max. 150 Mbps

*1 At the WPS setting stage, the settings are established automatically according to the authentication and encryption systems set at the access point.
